The Cisco Aironet 1140 Series Access Point is a business-ready, 802.11n access point designed for simple deployment and energy efficiency. The high-performance platform, which offers at least six times the throughput of existing 802.11a/g networks, prepares the business for the next wave of mobile devices and applications. Building on the Cisco Aironet heritage of RF excellence, the 1140 Series combines the industry's most widely deployed 802.11n technology with a sleek industrial design that blends seamlessly into any enterprise environment. Designed for sustainability, the 1140 Series delivers high performance from standard 802.3af Power over Ethernet while decreasing waste with multiunit eco-packs and Energy Star certified power supplies. As part of the Cisco Unified Wireless Network, the 1140 Series provides the industry's lowest total cost of ownership and investment protection by integrating seamlessly with the existing network.
| Manufacturer: | Cisco Systems, Inc |
|---|---|
| Manufacturer Part Number: | AIR-AP1142N-T-K9 |
| Manufacturer Website Address: | www.cisco.com |
| Brand Name: | Cisco |
| Product Line: | Aironet |
| Product Series: | 1140 |
| Product Model: | 1142N |
| Product Name: | Aironet 1142N Wireless Access Point |
| Product Type: | Wireless Access Point |
| Wi-Fi Standard: | IEEE 802.11n |
|---|---|
| ISM Band: | Yes |
| UNII Band: | Yes |
| ISM Minimum Frequency: | 2.41 GHz |
| ISM Maximum Frequency: | 2.46 GHz |
| UNII Minimum Frequency: | 5.28 GHz |
| UNII Maximum Frequency: | 5.83 GHz |
| Number of Antennas: | 4 |
| Antenna Gain: | 3 dBi |
| 4 dBi | |
| Wireless Transmission Speed: | 300 Mbps |
| Wireless Security: |
|
| Features: | MIMO Technology |
| Ethernet Port: | Yes |
|---|---|
| Fast Ethernet Port: | Yes |
| Gigabit Ethernet Port: | Yes |
| 10Gigabit Ethernet Port: | No |
| Number of Network (RJ-45) Ports: | 1 |
| Network (RJ-11): | No |
| PoE (RJ-45) Port: | Yes |
| VGA: | No |
| Serial Port: | No |
| USB: | No |
| Powerline: | No |
| Management Port: | Yes |
| Input Voltage: | 57 V DC |
|---|---|
| Power Source: | AC Adapter |
| Form Factor: | Ceiling Mountable |
|---|---|
| Height: | 1.8" |
| 46.7 mm | |
| Width: | 221.0 mm |
| 8.7" | |
| Depth: | 221.0 mm |
| 8.7" | |
| Weight (Approximate): | 1.04 kg |
| 2.30 lb |
| Certifications & Standards: | IEEE Standards:
Safety:
Radio approvals:
Multimedia:
Other:
|
|---|---|
| Green Compliant: | Yes |
| Green Compliance Certificate/Authority: | Energy Star |
| Limited Warranty: | Lifetime |
|---|
| Limited Warranty: | Lifetime |
|---|
| Sku | Description | Price | Order |
|---|---|---|---|
2020697BC |
Cisco SMARTnet - 1 Year Extended Service--24 x 7 x 4 Hour |
$152.15 |
